1. What is a composite?

In the beginning, I’d like to define the word “composite” in a very simple sentence: Two different materials that just lock together and they’re not dissolved, creating a new material that has properties we need for a specific application.

These two materials have various physical and chemical properties. When they create a composite, the new material will have new properties, unlike the constituent materials. Properties such as becoming stronger, lighter, or electrically resistant.

One of these materials is called “Matrix” which has soft properties compared to the other one. The other material which we could call the “reinforcement” has stiffer and stronger properties compared to the Matrix. The reinforcement part is surrounded by the Matrix, and you may know it as fibers.

Some examples of composite materials

• Human Hair
• Wood
• Bone
• Mud bricks
• Translucent Concrete
• Absorbent concrete
• Fiberglass
• Carbon Fiber
• Kevlar

Now that you know what composite material is, let’s talk about “why we need them?”  What are the advantages and disadvantages of these materials?

I’m sure you have noticed that some of the examples above are natural composites. If you want to be familiar more with natural composites their design, applications, and simulations, we have a course for that: “Advanced Materials Engineering: Design, Simulation, and Applications of Natural Fiber Composites”

2. Why do we need composites?

Compared to other common materials, composites are known mostly because of their strength and lightness. Imagine you want to design a plane; you must select a material with properties such as high strength, being as light as possible to fly, and being flexible. Common materials like steel have the strength we need, but they’re heavy and do not have the flexibility we need. Well, the best choice would be composite.

Manufacturers can create qualities that precisely meet the needs of a specific structure for a specific purpose by selecting the right reinforcing and matrix material mix. Take a look at the table below; there are some advantages and disadvantages of these materials.

Some practical examples of composite materials are:

Buildings (e.g., Reinforced concrete with CFRP), bridges, and other constructions, including boat hulls, swimming pool panels, racing car bodies, airplanes, storage tanks, etc. Additionally, they are being employed more and more in standard automotive applications.

Reinforced concrete with CFRP

Moreover, you can see them in your house and kitchen. Bathtubs, shower stalls, replica granite, cultured marble basins, and countertops are frequently made of composite materials.

⭐⭐⭐Free Abaqus Course | ⏰10 hours Video  👩‍🎓+1000 Students   ♾️ Lifetime Access ✅ Module by Module Training                                  ✅ Standard/Explicit Analyses Tutorial ✅ Subroutines (UMAT) Training                    …           ✅ Python Scripting Lesson & Examples …………………………                 …………………….. ……………   ………………………………………………..Start Free Abaqus Course

Still with us, right?!

Now, let’s see the composite material classifications.

3. Composite classifications

As we said before, the composites are made of two materials; one is called the “matrix,” and the other is called “reinforcement”. Therefore, the composites can be classified based on two criteria:

1. Based on the “matrix” material
2. Based on the “reinforcement” material

Each of them will divide into several types. To understand composite analysis, it is important to know these two materials and their role in composite structures.

The first criterion divides into three types: Organic Matrix Composites (OMCs), Metal Matrix Composites (MMCs), and Ceramic Matrix Composites (CMCs).

The second criterion divides into five types: Particle Reinforced Composites, Flake Reinforced Composites, Fiber Reinforced Composites, Structural Composites, and Nanocomposites.

Don’t worry! We’ll explain them all in the simplest way possible with practical examples.

3.1. Based on Matrix material

The composites are classified into three types based on this criterion:

1. Organic Matrix Composites (OMCs): Generally, OMC refers to two types of composites; Carbon matrix composites which you may know of them by the name Carbon-Carbon composites; and Polymer Matrix Composites (PMCs).

• Polymer matrix composites (PMCs) have drawn a lot of attention, largely because they are more affordable and have higher stiffness and specific strength than traditional metallic alloys. Additionally, PMCs provide greater design freedom and better corrosion and fatigue resistance. But, they have some disadvantages and the most important of them are low working temperatures, high coefficients of thermal and moisture expansion, and poor elastic characteristics in some directions. The use of PMCs has been well-established in the automotive and aerospace industries for many years, and it is now finding new uses in the biomedical, marine, and infrastructure industries. Now, let’s see some applications of the PMCs:
  • Construction of structural components for satellite systems, space shuttles, and military aircraft.
  • Sporting goods include athletic footwear, sports gear, and other related products.
  • Applications for implants, orthopedic equipment, MRI scanners, X-ray tables, and prostheses in the field of medicine.
  • Protective gear for armor such as bulletproof vests.
  • Body panels, leaf springs, driveshafts, bumpers, doors, etc. are used in the automotive industry.
• Carbon fibers and carbon matrices make up carbon/carbon composites. Some advantages of these composites are: Withstand in high-temperature situations like up to 6000°F (3315°C), low density, good compressive and tensile strengths, high fatigue resistance, low creep at high temperatures, etc. But like other materials, this one has its own disadvantages as well such as high cost, low shear strength, oxidation vulnerability at high temperatures, etc.

Some applications of Carbon-Carbon composites:

• • Rocket motor nozzle throats and exit cones, nosetips/leading edges, and thermal protection systems are examples of aerospace components that are frequently made from carbon/carbon composite materials.
  • furnace fixturing
  • load plates
  • heating elements
  • heatshields
  • X-ray targets

2. Metal Matrix Composites (MMCs): A composite material called metal matrix composite (MMC) has fibers or particles spread in a metallic matrix made of steel, copper, or aluminum. Usually, a ceramic (such as silicon carbide or alumina ) or another metal (such as steel) makes up the reinforcement phase. Over polymeric matrices, metal matrices have the benefit of being appropriate for usage in applications requiring long-term resistance to harsh conditions. It is true that most metals have higher yield strengths and modulus than polymers. The ability to plastically deform and strengthen metals through numerous heat and mechanical processes is another benefit of using metals. Some advantages of MMCs are high specific strength and stiffness, operating in a wide range of temperatures, being fire resistant,  do not absorb moisture, high compression strength, higher electrical and thermal conductivity compared to PMCs, etc. Several disadvantages of MMCs are the high cost of some material systems, limited service experience, etc. But let’s see some applications of the MMCs:

• • Tank armors
  • Carbide drills
  • In the automotive industry, such as driveshaft, engines, and disk brakes.
  • Space systems
  • Pushrods for racing engines
  • In the aircraft components, such as the structural component of the jet’s landing gear.

3. Ceramic Matrix Composites (CMCs): In Ceramic Matrix Composites (CMCs), ceramic materials are used for both matrix and reinforcement parts. Any ceramic material can be used to make the matrix and fibers. For example, the matrix can be made of Calcium aluminosilicate and the reinforcement part can be fibers such as carbon or silicon carbide. The advantages of the CMCs are including applications in extreme service temperatures, chemical inertness, high creep resistance and thermal shock, low density, high fracture toughness compared to conventional ceramics, etc.

Did you know that the composites such CMCs have the finishing process like grinding? Or do you have any idea about the machining techniques for composite materials? Here we introduce you with all of that and more in our course: “Advanced Machining Techniques for Ceramic Matrix Composites: Grinding Processes and Material Behavior”

However, these materials have some disadvantages as well, such as shape limitation and part size, brittle fracture, low impact resistance, etc.
Some uses of CMCs are:

• • Turbine blades
  • Bulletproof armor
  • Immersion burner tubes
  • Heat exchangers
  • Rocket propulsion components
  • Turbojet engine components

I didn’t bore you so far, did I?! Let’s get to the next criterion.

3.2. Based on Reinforced material

We have five types based on this criterion:

1. Particle Reinforced Composites: Particle-reinforced composites are made up of a matrix that has been strengthened by a dispersed phase made up of particles. Some advantages of this type are including oxidation resistance, these have lower cost and are simpler to produce and construct compared to fiber-reinforced ones, high wear resistance, etc. This one divides into two levels; large particle composites like concrete and dispersion-strengthened composites. Some common examples of this type are:

• • Concrete
  • Particle board
  • Road surfaces

Schematic of Particle Reinforced composite [Ref]

2. Flake Reinforced Composites: This type consists of flat reinforcements of matrices. High out-of-plane flexural modulus, increased strength, and the inexpensive price is a few benefits of this type. However, flakes can’t be easily orientated and there aren’t many materials that can be used. Glass, mica, aluminum, and silver are examples of common flake materials.

Schematic of Flake Reinforced composite [Ref]

3. Fiber Reinforced Composites: This type consists of matrices reinforced by fibers. Just take a look at the figure below to get an idea of what is the fiber-reinforced composite.

Schematic of Fiber Reinforced Composite [Ref]

Regarding the size of the fiber, fiber-reinforced composites are divided into two categories: continuous and discontinuous. When referring to fibers that are as long as the composite material, the phrase “continuous-fiber-reinforced composite” is used, whereas “discontinuous-fiber-reinforced composite” is used to describe fibers that are relatively short in contrast to the size of the composite material. The fibers could be distributed aligned or at random in the discontinuous type. See the figures below to understand better. Composite simulation

[Ref]

The continuous type could be aligned unidirectional,  bidirectional, or even woven.

Different types of fiber-reinforced composites [Ref]

In unidirectional composites, all fibers are aligned in a single direction; therefore, despite having high mechanical strength, unidirectional fiber-reinforced composites are weaker under transverse tension than they are under longitudinal tension. So, they shouldn’t be used for parts that need a significant anisotropic strength (strength in all directions). When front-to-back strength is crucial, unidirectional reinforcement is the best option. For instance, unidirectional carbon fiber is frequently used as reinforcement in long, tubular structures that can only move forward and backward, such as boats, rockets, and airplanes. for getting more valuable insights about unidirectional composite damage read the related post.

In bidirectional composites, all fibers are aligned in two unique directions. In this type ultimate strength is low, but occurs in two unique directions. Reduced ultimate strength occurs when characteristics are constant in all directions and the direction of the fibers becomes more statistically varied across the composite. (composite simulation is described in the next sections)

The discontinuous fiber-reinforced composite may also be referred to as the short fiber-reinforced composite. Hence, when short (chopped) fibers are combined with the matrix, they create a composite known as short fiber reinforced composite. Depending on the intended application, the fibers within this composite may be arranged in either an aligned or random manner within the matrix.

Woven composites are net-shaped composite structures that are fully interconnected by their yarns. Like a piece of cloth, the yarns are weaved together as warp and weft to create a 3D composite structure.

I know you might get confused with all these categories. But take a deep breath and look at the pictures again. The pictures always help to better understand something.

Now, it’s time to see some practical examples of Fiber-Reinforced Composites (FRCs):

Glass Fiber Reinforced Polymer (GFRP), Carbon Fiber Reinforced Polymer (CFRP), etc. The most common CFRP composite productions are Tennis rackets, golf clubs, softball bats, hockey sticks, and archery arrows and bows. Some applications of GFRP are in Electronic enclosures, Water pipes or drain coverings, and Sporting equipment such as kayaks, Helicopter rotor blades, wind turbine blades, etc.

4. Structural Composites: This type comes into two models; Laminar composites and Sandwich composites. Don’t forget to get your Abaqus files for modeling these two composite structures for free at the end of this section.

An assembly of fibrous composite material layers that can be linked to provide the necessary technical qualities, such as in-plane stiffness, bending stiffness, strength, and coefficient of thermal expansion, is known as a composite laminate. Each layer may comprise unidirectional continuous fibers, short fibers, or braided or woven fibers embedded in a matrix. Depending on the projected loading of the structure where the laminate will be utilized, the plies are laid out differently.

Composite laminate [Ref]

composite laminate specimen

A hybrid laminate can be created by layering various materials. The laminate then exhibits anisotropic (with variable direction of principal properties), orthotropic, or quasi-isotropic properties, depending on whether the individual layers are orthotropic (that is, with principal properties in orthogonal directions) or transversely isotropic (with isotropic properties in the transverse plane). Although not limited to isotropic out-of-plane (bending) response, quasi-isotropic laminates show isotropic (i.e., direction-independent) inplane response. The laminate may demonstrate coupling between in-plane and out-of-plane response depending on the order in which the various layers are stacked.

Due to their high strength and lightweight nature, laminated composite materials have become more essential in engineering applications including aerospace and automotive structures.

Sandwich plates are made up of a core covered by facesheets. Due to their high bending stiffness-to-weight ratio, sandwich plates are widely utilized in place of solid plates. The distance between the load-bearing facesheets causes the high bending stiffness; and the core’s lightweight causes the structure lightweight. Each facesheet must be thin in comparison to the core, whether it be an isotropic material or a fiber-reinforced composite laminate. Foam or honeycomb may be used for the core, which must have a material symmetry plane parallel to its midplane and have less in-plane stiffness than the facesheets.

[Ref]

Sandwich composite

Now, I’m sure you want to know the applications of these structures:

In aircraft, where mechanical efficiency and weight reduction are crucial, this is a natural application. There are other applications in automotive and transportation.

These prefabricated components are made for use as building envelopes in the building and construction industry. They can be found in commercial and office buildings, clean and chilly spaces, as well as in renovated or newly constructed residential homes. They blend a premium product with significant design freedom. They are generally sustainable and have good energy efficiency.

Polypropylene honeycomb boards and fluted polypropylene boards are used in packing.

I hope you are not bored yet! But don’t worry, we’re going to tell you the final type.

Check this out! A free Abaqus modeling file for composites, just enter your email and get your files. One example for Sandwich panels and another for Laminated composites:

5. Nanocomposites: Materials of the scale of nanometers make up nanocomposites (10–9 m). A constituent must be less than 100 nm in order for something to be considered a nanocomposite. Materials’ characteristics at this size differ from those of the bulk material.
Advanced composite materials typically have microscale components (10–6 m). The majority of the qualities of the resulting composite material are superior to those at the microscale, thanks to the use of nanoscale components. However, some nanocomposites’ qualities, like toughness and impact strength, can actually worsen.

Nanocomposite films have improved qualities including elastic modulus and transmission rates for water vapor, heat distortion, and oxygen in packaging applications for the military, among other uses.

As there are many types of composites, Composites Abaqus analysis can help us choose the best type for a specific application. Let’s take a look at composite analysis to better understand this process.

[learn_press_recent_courses]

4. Composite Analysis | Composite simulation

Analysis of Composite (composite simulation) is necessary for designers to ensure that composite structures are strong and stiff enough while minimizing weight. One useful method for composite analysis under loads is Classical Laminate Analysis (CLA). This theory is used to predict the strains, displacements, and curvature that emerge in a composite when it is exposed to mechanical and thermal loads. In other words, CLT can be used to analyze the behavior of composites with multiple plies. It can even be applied to composites that have a core in the middle. Composite Analysis and Abaqus composite simulation are fully discussed in this post.

Performing CLA manually can be challenging due to recurring computations and complex matrices. To simplify the process, Finite Element Analysis (FEA) software like Abaqus can be used. There are some differences between FEA for metal and composite in Abaqus. The element property card is different because the properties of each ply depend on its orientation.

All we have to do is to input Mechanical parameters like E1, E2, etc., for each lamina, followed by the desired stacking sequence.

composite simulation a ply stack plot [Ref]

Overall, using composite analysis and methods like CLA and FEA can help designers create strong, lightweight composite structures. (composite simulation)

After obtaining the stress and strains in composite materials (doing stress composite analysis), we usually have to study the composite damages to prevent failure in these materials. The following explanations provide information on this subject.

We are here at the CAE Assistant to explain some about composite material damage and introduce some FEM tools to simulate these damages correctly. Also, we will help you learn how to simulate and analyze your model and structure. With our high-quality education, you can learn how to work with Abaqus composite materials and perform accurate composite analysis.(Composite in Abaqus)

⭐⭐⭐Free Abaqus Course | ⏰10 hours Video  👩‍🎓+1000 Students   ♾️ Lifetime Access ✅ Module by Module Training                                  ✅ Standard/Explicit Analyses Tutorial ✅ Subroutines (UMAT) Training                    …           ✅ Python Scripting Lesson & Examples …………………………                 …………………….. ………………………………………………………………..Start Free Abaqus Course

4.1 Choosing the Right Tool for Your Composite Design

Modeling composite parts requires specialized software that can handle the unique properties and complexities of these materials. Here’s a breakdown of key factors to consider when selecting the right software:

• Functionality: Does the software offer dedicated tools for composite modeling? Look for features like ply definition, layup creation, and material libraries with common composite options.
• Geometry Complexity: How intricate is your part? Some programs excel at simple geometries, while others handle highly complex shapes efficiently.
• Analysis Needs: Will you be simulating the part’s performance under stress? Choose software with built-in Finite Element Analysis (FEA) capabilities or compatibility with dedicated FEA programs.
• Integration: Does the software seamlessly integrate with your existing CAD workflow? Compatibility with other design tools can streamline the process.
• Cost and User-Friendliness: Consider your budget and team’s skill level. While powerful programs offer extensive features, they might require specialized training.

Popular Professional Composite Design Software:

• ABAQUS: Industry-standard FEA software with robust composite modeling capabilities. Ideal for complex simulations but requires expertise.
• ANSYS: Another powerful FEA suite featuring composite material libraries and analysis tools. Suitable for advanced users.
• Siemens NX: A comprehensive CAD platform with a dedicated “NX Composites” module for defining layups, materials, and analyzing performance.
• Dassault Systèmes Abaqus Composite Design (ACD): Streamlined software specifically for composite design within the Dassault Systèmes 3DEXPERIENCE platform.

Simulation Considerations:

For simulating composite behavior under load, FEA capabilities are crucial. Both ABAQUS and ANSYS offer top-tier simulation tools. However, dedicated composite design software like NX Composites and ACD often integrate seamlessly with their own simulation modules, simplifying the workflow.

Ultimately, the best software depends on your specific needs and project complexity. Consider demos, trials, and user reviews to find the program that best suits your requirements and expertise.

5. Abaqus composite modeling

Until now, you’ve learned so much about composite materials in this Abaqus composite tutorial. You’ve learned “What is a composite material?”, “why we need them?”, advantages and disadvantages of composites, classification of composites, and composite analysis. Now, we’re ready to talk about how to model and analyze these magnificent structures in the Abaqus software. Just don’t forget the Free examples at the end of this section which are the sandwich panel and laminate composite models. Composite Analysis and Abaqus composite

• First, we talk about how to model a composite in Abaqus, how to create parts, apply material properties, etc.
• Second, we talk about how to simulate damage in composites, damage initiation point, progressive damage, and the most important damage theories such as the HASHIN failure criteria, Tsai-Wu, Tsai-Hill, Puck criterion, etc.
• Third, fatigue in composites. (fatigue composite)
• And finally, we’ll see some practical examples and simulations of composite in Abaqus (composite simulation).

If you’re interested as we do and want to learn how to do your projects about composite analysis with the FEM method, let’s get right to it and see how to model composite in Abaqus.

5.1. Modeling

As we said, the first step for composite analysis is to model the composite in Abaqus. But you need to know something first. When you want to understand and analyze a complicated material like composites, you look at it from different angles and try to figure out the structure of the model; but what if you check the structure in different scales? Wouldn’t be better?

The understanding of complicated materials utilized in engineering practice can benefit from multi-scale models. in three scales, you can model and start the analysis of the composite structure (Composite Analysis): Macro (10⁰m), Meso (10^-3m), and Microscale (10^-6m). Look at the picture below to understand better.

Composite in different scales

Micro-scale (10^-6m): RVE analysis is a common method for micro modeling. In composite materials, Representative Volume Element (RVE) is the smallest volume in the structure, which represents the values and properties of the whole model. Each measurement that is made on this volume will yield a value that can be representative of the whole model.

Macro-scale (10⁰m):  In macro modeling, instead of separately modeling the components of the composite, the results of the laboratory, as well as the existing theories, suggest that the properties of the composite are introduced to the ABAQUS software in various ways. (common Abaqus composite modeling).

Now it is time to learn the Abaqus composite modeling in action and we have some examples for you below which you can have access by just entering your email:

Now, depending on your model and project, you need to choose a scale and start modeling your composite material. Don’t know how and where to start?! Don’t worry! We are here to help you. To start, read Composite simulation| composite analysis (lesson 5).

Need to know more? Check this out:

You can learn composite modeling and composite analysis with the mentioned methods in this Abaqus composite tutorial. Also, you learn how to model a woven composite in the Abaqus. This training package provides comprehensive basic information and examples of composite modeling in ABAQUS FEM software.

​

5.2. Composite Damage

Stress-strain curve for composite materials

In the Abaqus, we must define the “damage initiation” point and the “progressive damage” area; to do so, there are different theories that come in. Learn more about Composite Damage.

5.2.1. Abaqus criteria

Like any material, composites are susceptible to damage under various loading conditions. Predicting this damage is crucial for ensuring the lifespan and performance of composite structures. This is where failure criteria come in.

Essentially, failure criteria are like thresholds of stress or strain that, when exceeded, indicate the onset of damage in a composite. By incorporating these criteria into numerical simulations, engineers can identify potential weak spots and predict how the material will behave under specific loads. Composite simulation

You can learn about most common failure criteria used in Abaqus via this link:

Damage criteria in Abaqus/CAE

The Abaqus capabilities of modeling the damage and progressive damage based on different criteria in the GUI limit only to shell elements.

HASHIN criterion:

In the below package, all available criteria on Abaqus about composites are introduced, and there are some workshops that teach you how to model correctly in Abaqus. Both stress-based and strain-based theories are presented in this package.

5.2.2. HASHIN criterion for 3D elements

There are different criteria for damage initiation as well as how to reduce the mechanical properties. Three-dimensional HASHIN damage, which involves detecting damage to fibers, matrix, and delamination, is very common. It should be mentioned that progressive damage can be done by reducing the properties suddenly or gradually with different energy methods or equations. Composite Analysis and Abaqus composite simulation.

5.2.3. TSAI criterion for 3D elements

There are also some tutorial packages in this field that will be available on the CAE assistant shop soon.

5.2.4. Puck criterion

There are also some tutorial packages in this field that will be available on the CAE assistant shop soon.

5.2.5. Hybrid composite

There are also some tutorial packages in this field that will be available on the CAE assistant shop soon.

5.3. Composite fatigue

The primary failure mechanism for structures subject to cyclic loading is fatigue. Abaqus is a software that offers various fatigue criteria to predict the fatigue life of materials and structures under cyclic loading conditions. There are several commonly used fatigue criteria supported by Abaqus, including the Stress-Life (S-N) Curve, Strain-Life (ε-N) Curve, Fatigue Damage, Critical Plane Analysis, and Energy-Based Criteria. The Stress-Life Curve is typically used for metallic materials, while the Strain-Life Curve is used for composite materials.

Several factors can affect the fatigue behavior of composite materials, such as loading frequency, stress level, temperature, moisture, and aging. These factors can accelerate or retard the onset of fatigue damage and affect the fatigue life of the composite(fatigue composite)

Fatigue loads can be classified based on their amplitude, which can be constant or variable. Here’s a brief overview of each:

1. Constant Amplitude Fatigue Load: This type of fatigue load has a constant stress or strain amplitude throughout the loading cycle. The loading history is repetitive and predictable, and the fatigue life can be estimated using S-N curves or other methods.
2. Variable Amplitude Fatigue Load: This type of fatigue load has a varying stress or strain amplitude throughout the loading cycle. The loading history can be random or Deterministic. The fatigue life estimation for variable amplitude fatigue loads is more complex and requires the use of statistical methods such as damage accumulation or Rainflow cycle counting.

You can see the fatigue load classification in the figure below:

[Ref]

so analysis of composite fatigue(fatigue composite) is very important due to the possible failure costs. Here we have fatigue analysis of unidirectional composites with the UMAT and VUMAT subroutines which use the Shokrieh fatigue theory; Also, there are fatigue analysis of woven composite, short fiber composite, and Balsa wood.

5.3.1. Unidirectional composite

5.3.2. Woven composite

In this training package(composites Abaqus), the modified Hashin fatigue damage model based on the article titled  “Life prediction of woven CFRP structure subject to static and fatigue loading “ is used. In this fatigue model, strength and elastic properties reduction and fatigue life are calculated.

5.3.3. Short fiber composite

The fatigue simulation of short fiber composites with subroutine package is based on “Fatigue behavior and cyclic damage of peek short fiber reinforced composites”  article, and the subroutine has been implemented based on the mentioned article. However, this article has used the USDFLD subroutine, but we use the UMAT subroutine in this Abaqus composite tutorial, which is more accurate than USDFLD since the material strength and properties reduction is smooth. Read more: Short Fiber Composite Fatigue Analysis

5.3.4. Wood

This training package focuses on writing subroutines to simulate wood fatigue in Abaqus. In the “Balsa wood fatigue simulation with subroutine” package, the used fatigue theory of wood has been described. Then, the flowchart of the subroutine and writing subroutine line-by-line is explained. It helps users to develop the subroutine based on customized theory. Also it can be extended to other Abaqus composite materials with properties close to wood. Finally, the subroutine is implemented on the Abaqus model, and the results are discussed.

5.4. Composite structure

Due to the increasing growth of science and industry, there is a need to develop advanced materials with more profits. Abaqus composite materials, due to their higher efficiency and economic benefits, have become a suitable alternative to traditional materials in various industries. Therefore, the development of these materials by understanding how to produce and study their properties using Abaqus software is essential. The composites are used in many fields such as pressure vessels, aerospace, military, civil structures, etc.

5.4.1. Composite pressure vessel

A composite pressure vessel is a type of pressure vessel made of composite materials, such as carbon fiber reinforced polymer (CFRP), that offers high strength-to-weight ratio and corrosion resistance. Composite Pressure vessel design involves modeling the composite material behavior under various loading conditions using finite element analysis (FEA) software. The design and analysis of a composite pressure vessel can be successfully performed using Composites Abaqus simulations
